VVDI/AVDI Device Only

Stock Code	GK-4001-1
Barcode	8684990060637
EAN	8684990060637
Categories	VVDI/Avdi Compatible Test Platformu
Brands	Goldcar Products
Tags	VVDI/AVDI Device Only

Description Comments (0) Product Information Product Features

Product Features

Manufacturer	Condition	Weight
Goldcar	New	240 g

Supports testing of FBS4 ECU, Working with Xhorse VVDI MB, Key Tool Plus, Autel MaxiIM IM508, IM608, CGDI Benz, AVDI Programmer and so on.

Compatible with VVDI/AVDI

VVDI/AVDI Device

EIS ESL Dashboard Gateway Testing Tool Highlights

Supports old and new FBS4 EIS testing
Built in Gateway enable you testing the EIS without connecting extra gateway
Compatible with Mercedes key programmers such as:

VVDI MB Tool
AVDI
ZED-FULL
CGDI Mercedes
MBE TOOLS
AUTEL IM508, IM608

• And others …

EIS ESL Dashboard Gateway Testing Tool Features:

The new device designed for on-bench testing of EZS (EIS), ESL (ELV), Dashboard & gateway Comes with built in ESL Emulator inside and has automatically mode switching
It enables you to test the EIS with the car ESL or with the emulator if original ESL / ELV is not available using Emulation mode.
You can test both old (Motorola based EZS) and new (NEC based) units without the car – just connect them with special set of cables.
The new Generation comes with built in ESL / ELV emulator for W204, W207 to test the EIS without the original ESL / ELV (must be programmed before testing)

EIS ESL Dashboard Gateway Testing Tool Supported List

EIS/EZS:

W208 / W210 ( Embedded Emulator ) Avdi and VVDI MBTOOL read password + Elv control + Obd control
W209 / W211 ( Embedded Emulator & Embedded GateWay ) Avdi and VVDI MBTOOL read password + Elv control + Obd control
W169 / W245 ( Embedded Emulator & Embedded GateWay ) Avdi and VVDI MBTOOL read password + Elv control + Obd control
W203 / W639 / VITO ( Embedded Emulator ) Avdi and VVDI MBTOOL read password + Elv control + Dash board control + Obd control
W906 / CRAFTER / SPRINTER ( Embedded Emulator ) Avdi and VVDI MBTOOL read password + Elv control + Dashboard control + Obd control
W215 / W220 Avdi and VVDI MBTOOL read password + Obd control
W204 / W207 / W212 Avdi and VVDI MBTOOL read password( W204/W212 Embedded Emulator ) + Elv control + Obd control + Dashboard control
W164 Avdi and VVDI MBTOOL read password ( Embedded GateWay )+ Obd control
W221 Avdi and VVDI mbtool read password + Obd control
W246 Avdi and VVDI mbtool read password + Dashboard control + Obd control
W212 Avdi and VVDI mbtool read password + Dashboard control + Obd control
New – W447 / W176 new model ( FBS4 + FBS3 ) read password ready + Dashboard control + Elv control + Obd control
New – W222 / W205 new model ( FBS4 + FBS3 ) read password ready + Dashboard control + Obd control

VVDI/Avdi Device

Product Description

Manufacturer	Condition	Weight
Goldcar	New	240 g

Supports testing of FBS4 ECU, Working with Xhorse VVDI MB, Key Tool Plus, Autel MaxiIM IM508, IM608, CGDI Benz, AVDI Programmer and so on.

Compatible with VVDI/AVDI

VVDI/AVDI Device

EIS ESL Dashboard Gateway Testing Tool Highlights

Supports old and new FBS4 EIS testing
Built in Gateway enable you testing the EIS without connecting extra gateway
Compatible with Mercedes key programmers such as:

VVDI MB Tool
AVDI
ZED-FULL
CGDI Mercedes
MBE TOOLS
AUTEL IM508, IM608

• And others …

EIS ESL Dashboard Gateway Testing Tool Features:

The new device designed for on-bench testing of EZS (EIS), ESL (ELV), Dashboard & gateway Comes with built in ESL Emulator inside and has automatically mode switching
It enables you to test the EIS with the car ESL or with the emulator if original ESL / ELV is not available using Emulation mode.
You can test both old (Motorola based EZS) and new (NEC based) units without the car – just connect them with special set of cables.
The new Generation comes with built in ESL / ELV emulator for W204, W207 to test the EIS without the original ESL / ELV (must be programmed before testing)

EIS ESL Dashboard Gateway Testing Tool Supported List

EIS/EZS:

W208 / W210 ( Embedded Emulator ) Avdi and VVDI MBTOOL read password + Elv control + Obd control
W209 / W211 ( Embedded Emulator & Embedded GateWay ) Avdi and VVDI MBTOOL read password + Elv control + Obd control
W169 / W245 ( Embedded Emulator & Embedded GateWay ) Avdi and VVDI MBTOOL read password + Elv control + Obd control
W203 / W639 / VITO ( Embedded Emulator ) Avdi and VVDI MBTOOL read password + Elv control + Dash board control + Obd control
W906 / CRAFTER / SPRINTER ( Embedded Emulator ) Avdi and VVDI MBTOOL read password + Elv control + Dashboard control + Obd control
W215 / W220 Avdi and VVDI MBTOOL read password + Obd control
W204 / W207 / W212 Avdi and VVDI MBTOOL read password( W204/W212 Embedded Emulator ) + Elv control + Obd control + Dashboard control
W164 Avdi and VVDI MBTOOL read password ( Embedded GateWay )+ Obd control
W221 Avdi and VVDI mbtool read password + Obd control
W246 Avdi and VVDI mbtool read password + Dashboard control + Obd control
W212 Avdi and VVDI mbtool read password + Dashboard control + Obd control
New – W447 / W176 new model ( FBS4 + FBS3 ) read password ready + Dashboard control + Elv control + Obd control
New – W222 / W205 new model ( FBS4 + FBS3 ) read password ready + Dashboard control + Obd control

VVDI/Avdi Device
